We offer highly efficient HT/LT Bus Duct and rising mains. This is offered with both indoor and outdoor construction with IP42/55 degree of protection. The type of bus duct is offered in aluminum and copper based and manufactured as per the International Standards. SCPPL designs bus duct systems in a way that it allows you to have multiple outputs from it without any power loss. Our manufactured Bus Bar Chambers needs very less maintenance.



Applications	Operation, Control & protection of distribution network with or without PLC/BMS Connectivity
System	3 Phase, 3 or 4 wire, 50Hz
Rated Current	Upto 6300 Amps
Operational Voltage	415v AC
Rated Insulation	1000v
Rated Service Voltage	690v
Ambient Temperature	45 Deg C
Short Time Current	50KA for 1Sec, 105KA peak
Degree of Protection	IP42 for indoor installation, IP55 for outdoor installation
Form of Sepration	Upto 3B/4B (Optional Type 5)
Type Tested for	Short Time Current withstand Temperature Rise Degree of Protection
Type	Totally enclosed, Air insulated, Non segregated
Enclosure	Epoxy Powder Cated CRCA Sheet
Neutral	50% / 100% (Optional)
Earthing	Separate Earth bus provided on enclosure
Bus Bar Insulation	Black PVC insulation with colour coding for phase identification black matt paint for bus bar rating 2500A and above
Ref. Standard	IEC61439-12009, IS:8623
